Claricon Max Z Slit Lamp
Claricon Max Z Slit Lamp – ZEISS Style
Precision-engineered with handcrafted crystalline optics for superior clarity. Features 5-step magnification (6x–40x), smooth mechanical controls, LED illumination, and built-in filters. Designed for detailed ocular examination with ZEISS-style ergonomics.
Claricon Max Z Slit Lamp – ZEISS Style with Crystalline Optics
The Claricon Max Z Slit Lamp features handcrafted crystalline optics designed exclusively for the Claricon Series, delivering exceptional clarity and detail. Each lens is individually polished to ensure the highest optical performance, giving practitioners the ability to examine even the most delicate structures of the eye with precision.
This model offers smooth, high-precision mechanical design, intuitive controls, and brilliant LED illumination. Whether you're performing routine exams or detailed ocular assessments, no detail is missed.
Key Features:
- Five-Step Magnification: 6x, 10x, 16x, 25x, 40x
- Eyepiece: 12.5x with -7D to +7D adjustment
- Pupillary Distance: Adjustable from 54 mm to 82 mm
- Slit Width: Continuously adjustable from 0 mm to 14 mm
- Slit Height: Continuously adjustable from 1 mm to 14 mm
- Spot Diameters: 14 mm, 10 mm, 5 mm, 3 mm, 1 mm, 0.2 mm
- Slit Rotation: 0°–180°
- Built-in Filters: Heat, Gray, Green (Red-free), Blue (Cobalt)
- Fixation Target: Red LED 3.5V
- LED Illumination: 12V, 50W
- Input Voltage: 100–240V | Frequency: 48–62 Hz
- ZEISS-style mechanical design for reliable and familiar ergonomics
